Article details
Conforms to BS EN 12209Assessed for use on 30 minute (FD 30) and 60 minute (FD60) timber fire doors to BS EN 1634-1Deadbolt operated by cylinderCase: Galvanized, 16 mm wideForend: Radius, 2 pieceStrike plate: Radius. Box includedDeadbolt: Bright zinc plated. 20 mm throwHoled for bolt through furniture at 38 mm centres
For door material
Wood
Version
Back lining for strike plate
Prepared for
Profile cylinder
Lock actuation
Key operated
Colour/finish
Satin stainless steel
Forend length
235 mm
Deadbolt version
Standard deadbolt
Classification in compliance with EN 12209
3|X|8|1|0|G|1|B|A|0|0
Fire resistance category
FD60
Häfele Lifetime Guarantee
10 years
Order reference
Order cylinder separately
Supplied with
Strike plateFixings
Warranty/guarantee information
This product is covered under Häfele’s Lifetime Guarantee.All products covered under the Häfele Lifetime Guarantee have met our quality standards and have been tested according to the relevant industry certification.All products under this guarantee are covered for normal use of the products in a domestic environment - for commercial environments our standard 12 month guarantee would apply.For more information go to:Services > Customer Support > Häfele Lifetime Guarantee
Technical data attributes
1808
Additional information attributes
Where a fire rating is shown for a product this would only have been achieved by use of intumescent seals. When fitting any ironmongery to a door please ensure the correct intumescent product is used
