Article details
Specification:Concealed fixing cam action door closer with concealed guide rail arm for doors up to 1100 mm wide with adjustable closing force and latching action closing speed and adjustable hydraulic backcheckSuitable for doors over 40 mm thickHold open angle infinitely variable between 80° and 120°Features:Cam action closerFully concealed guide rail armClosing force adjustable (size range EN 2-4)Adjustable closing speedAdjustable backcheckAdjustable latching speedCertification:Tested and approved to BS EN 1154: 1997Tested to conform with CE requirementsCertifire approved; certificate no. CF242 60 minsElectrical data:Operating voltage 24V DC ± 10%Connecting load 100mAMax. permissable ripple 20%Rating 100%Enclosure rating IP43A suitable switch should be installed for test purposes
Area of application
Door closer and guide rail for concealed installation in door
Version
with electromechanical hold-open function
For number of doors
1-leaf doors
Adjustment facility
Closing force and closing speed continuously adjustable,Latching action hydraulically adjustable,hydraulic soft opening mechanism adjustable
Closing force
2–4 in accordance with EN 1154
For door width
≤1,100 mm
For door thickness
≥ 42 mm
For door weight
≤130 kg
Hold-open angle
80 – 120 °
Standard
Certified in compliance with EN 1154:1996/A1:2002
Grade
3|8|2 – 4|1|1|4
Supplied with
1 Basic closer1 Guide rail
Technical data attributes
Fire resistance and smoke controlFire resistanceYesFS standardTested for fire resistant and smoke control doors.
