Article details
Area of application
For shelf support strip with apertures at 25 mm intervals
Suitable for
Shelf support strip with intervals of 25 mm
Material
Aluminium
Load bearing capacity per item
12.5 kg
Load bearing capacity with 4 shelf supports
50 kg
Note on load bearing capacity
tested in accordance with DIN EN 16337:2013-08 with 1.7 kg plate for impact test, i.e. 50 kg load bearing capacity when using 4 shelf supports
Installation
For hooking in
Adherence to standards
In accordance with DIN EN 16337:2013, i.e. 100 kg test load; with 1.7 kg striking cap
Order reference
For use with shelf support strips 283.12.013/803/903 which are available to order separately
Additional information attributes
The load capacity of the shelf support is dependent on shelf material and shelf depth
