Article details
Closure travel180°
Colour/finishNickel plated
Area of application
For on-site installation of cylinder cores and in the front panel
Version
With lifting pin
Material
Zinc alloy
Cylinder shape
prepared for round cylinder
Cylinder housing length
22 mm
Cylinder Ø
18 mm
Installation
For installation in fixed front panelfor screw fixing
Installation reference
The cylinder cores adapt flexibly to the locking plan requirements and can be installed on site. The cylinder cores are inserted without tools using the key. Additions and modifications can be implemented easily at any time by exchanging the cores.
with key
No
Order reference
Only use Premium 20 cylinder cores with restricted rotation and direction (DIN right) when using pin tumbler cylinder removable cores.
Additional information attributes
The cylinder cores adapt flexibly to the locking plan requirements and can be installed on site. The cylinder cores are inserted without tools using the key. Additions and modifications can be implemented easily at any time by exchanging the cores.
