Article details
For locking in mounting bracket
Light permeability60 – 70 %
Version
For concealed fixing
Material
Profile: Aluminium, Diffuser: Polycarbonate
Diffuser width
11 mm
Installation
For screw fixing with mounting clip
Häfele Lifetime Guarantee
7 years
Order reference
The diffuser creates a uniform light. The LED points are invisible from 120 LEDs/mIf required, please order alternative diffusers in black opal or transparent separatelyOrder end caps separatelyOrder mounting brackets separately
Supplied with
1x Surface mounted white opal diffuser, 70 - 80% transmittance
Warranty/guarantee information
This product is covered under Häfele’s Lifetime Guarantee.All products covered under the Häfele Lifetime Guarantee have met our quality standards and have been tested according to the relevant industry certification.All products under this guarantee are covered for normal use of the products in a domestic environment - for commercial environments our standard 12 month guarantee would apply.For more information go to:Services > Customer Support > Häfele Lifetime Guarantee
Additional information attributes
For LED strip lights up to a width of 8 mm. Slide-in 10 mm wide clips from the side before installing the profile.Distance of retaining clips max. 500 mm.The surface on the aluminium profile that is to be bonded must be cleaned before bonding to the LED strip lights. It must be completely clean, grease-free and dust-freeDiffuserThe opal white diffuser creates a uniform light without points from 120 LEDs/ m. Points are visible with black version. If required, please order alternative diffusers in black or transparent separately.
