Tectus TE240 3D 180D Hinge MN (f2) - Aluminium, Steel
Tectus TE240 3D 180D Hinge MN (f2) - Aluminium, Steel
- Maintenance free friction bearingsSuitable for left or right hand applications
- MountingFor DIN left and DIN right hand use
- Flange shaperounded
- ModelTE 240 3D
- Model series
- TECTUS TE 240 3D
Area of application
- For wooden, steel or aluminium framesFor flush doors
- For frame type
- Steel frame, Wooden frame, Aluminium frame
- Max. door weight for 2 hinges
- 40 kg
- Door thickness
- ≥25 mm
- Router bit Ø
- 16 mm
- Thrust ring Ø
- 30 mm
- Bearing type
- Friction bearing, maintenance-free
- Adjustment facility
- 3D, Side: ±3 mm, Height: ±3 mm, Closing pressure: ±1.5 mm
Order reference
- "Energy" version for permanent and invisible energy transmission from the door frame to the door leaf optionally available.
- Additional information attributes
- "Energy" version for permanent and invisible energy transmission from the door frame to the door leaf optionally available.
The Tectus TE240 3D 180D Hinge MN (f2) (product code 924.17.022) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Aluminium, Steel, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 924.17.022 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 924.17.022
- Material
- Aluminium, Steel
- Pack Quantity
- 1 Each
12 In stock
£106.38
Ex. VAT: £88.65
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 1 | £106.38 | — |
| 2 – 3 | £100.78 | Save 5% |
| 4+ | £89.58 | Save 16% |
- Technical Specifications
- Dimensions
| Material | Aluminium, Steel |
| Opening angle | 180 ° |
| Supplied with | Fixing screws |
| Flange width | 18 mm / 21 mm |
| Flange height | 155 mm |
