3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 340 3-way continuous adjustment Polished brass plated - Aluminium, Steel
3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 340 3-way continuous adjustment Polished brass plated - Aluminium, Steel
- Maintenance free friction bearingsSuitable for left or right hand applications
- MountingFor DIN left and DIN right hand use
- ModelTE 340 3D
- Model series
- TECTUS TE 340 3D
Area of application
- For wooden, steel or aluminium framesFor flush doors
- For frame type
- Metal frame, Aluminium frame, For wooden frame
- Max. door weight for 2 hinges
- 80 kg
- Door thickness
- ≥38 mm
- Router bit Ø
- 24 mm
- Bearing type
- Friction bearing, maintenance-free
- Adjustment facility
- Continuous
- 3-dimensional, Side: ±3 mm, Height: ±3 mm, Closing pressure: ±1 mm
Standard
- Certified in compliance with EN 1935:2002
- Grade
- 3|7|4|1|1|3|0|11
- Additional information attributes
- 'Energy' version for permanent energy transmission from the door frame to the door leaf optionally available. Additional cable transition not required.
The 3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 340 3-way continuous adjustment Polished brass plated (product code 924.17.169) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Aluminium, Steel, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 924.17.169 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 924.17.169
- Material
- Aluminium, Steel
- Pack Quantity
- 1 Each
9 In stock
£157.66
Ex. VAT: £131.38
- Technical Specifications
| Material | Aluminium, Steel |
| Opening angle | 180 ° |
| Supplied with | Fixing screws |
