• VersionUnhanded
• MountingLeft hand or right hand
• RefinementNickel plated

Area of application

• For continuous profile rod Ø 6 mm or 8 mmFor cylinder cores that are inserted from the front on site
• Please note that the pivot rods must be cut to the required size when designing the cabinet and choosing the accessories for the espagnolette lock.With the existing internal cabinet height ⓒ and installing the espagnolette lock at half height, the upper rod dimension is ⓐ and the lower rod dimension is ⓑ. Housing centre ⓓ – 25 mmDue to the three different backseats (15, 25 and 40 mm), identical gap sizes can be achieved for corner cabinets and rows of cabinets with the same drilling pattern.Note: Standard Nova, backset 40 mm is prepared for a continuous profile rod.
• Functionality
• The locking direction Ⓧ can also be reversed when the lock is already installed, in this case the lock must be locked.
• with key
• No

Order reference

• Order cylinder rosette and Hospa Ø 3.0 mm screws separately
