Symo3000 Gls Dr Lever Lockcase A PNP - Zinc Alloy Nickel Plated, Nickel Plated Polished
Symo3000 Gls Dr Lever Lockcase A PNP - Zinc Alloy Nickel Plated, Nickel Plated Polished
- Closure directions can be altered by re-positioning the cam, but always moving in the same direction*:Closure direction A can be altered to D, F or GClosure direction B can be altered to C, E or HClosure travel: 90º locking cam (reversible), 180º key
Area of application
- For cylinder cores that are inserted from the front on site
Suitable for
- With straight locking cam
- Version
- With straight cam
- For glass thickness
- 4 – 10 mm
- with key
- No
Order reference
- Please order counterpiece for 2-leaf sliding doors separately.
- Additional information attributes
- The locks can be operated by turning the protective cap with a screwdriver or coin, before the cylinder cores are installed
The Symo3000 Gls Dr Lever Lockcase A PNP (product code 233.42.600) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Zinc alloy, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 233.42.600 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 233.42.600
- Material
- Zinc alloy
- Colour / Finish
- Nickel plated, Nickel plated polished
- Pack Quantity
- 1 Each
97 In stock
£12.42
Ex. VAT: £10.35
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 9 | £12.42 | — |
| 10 – 19 | £11.80 | Save 5% |
| 20 – 49 | £11.18 | Save 10% |
| 50+ | £9.94 | Save 20% |
- Technical Specifications
| Material | Zinc alloy |
| Colour/Finish | Nickel plated, Nickel plated polished |
| Closure travel | 180° |
| Supplied with | 1 Locking cam1 Mounting nut1 Angled steel striking plate1 Clamping plate1 Clamping plastic rosette |
| Installation | Left hand |
| Cylinder shape | prepared for round cylinder |
