95D Hinge Clk 40 48/9 FO Sprung SF - Cup: Steel, Hinge Arm: Zinc Alloy Nickel Plated
95D Hinge Clk 40 48/9 FO Sprung SF - Cup: Steel, Hinge Arm: Zinc Alloy Nickel Plated
- For standard applicationsThe ⌀ 40 cup makes this an excellent choice for doors up to 36 mm thickness.
- Area of applicationFor standard applications
- Crank typeHigh Cranked
- Door processing for assemblywith cup drilling
- Cup drilling Ø40 mm
- Cup fixingfor screw fixing
Order reference
- Order Hospa ⌀ 3.5 mm raised head countersunk screws separately
The 95D Hinge Clk 40 48/9 FO Sprung SF (product code 322.13.631) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Cup: Steel, Hinge arm: Zinc alloy, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 322.13.631 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 322.13.631
- Material
- Cup: Steel, Hinge arm: Zinc alloy
- Colour / Finish
- nickel plated
- Pack Quantity
- 1 Each
56 In stock
£8.22
Ex. VAT: £6.85
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 9 | £8.22 | — |
| 10 – 29 | £7.81 | Save 5% |
| 30 – 49 | £7.40 | Save 10% |
| 50+ | £6.58 | Save 20% |
- Technical Specifications
- Dimensions
| Material | Cup: Steel, Hinge arm: Zinc alloy |
| Colour/Finish | nickel plated |
| Opening angle | 95° |
| Drilling pattern | 48/9 |
| Cup drilling depth | 13.2 mm |
