Concealed Hinge 105° Full Overlay Mounting Tiomos H AL For aluminium framed doors Nickel plated
Concealed Hinge 105° Full Overlay Mounting Tiomos H AL For aluminium framed doors Nickel plated
- Concealed hinge systemIntegrated soft close damper3D adjustmentFor cabinet thickness min. 18 mmCabinet rebate depth: 42 mm
- Adjustment facility
- Side adjustment: ±2 mm, Height adjustment: ±1.5 mm, Depth adjustment: -0.5 – 2 mm
Order reference
- Tiomos H AL adaptor and profile to be ordered separately
The Concealed Hinge 105° Full Overlay Mounting Tiomos H AL For aluminium framed doors Nickel plated (product code 348.21.520) is a Hafele engineered product built for dependable, precise performance in everyday use.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 348.21.520 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 348.21.520
- Pack Quantity
- 1 Each
29 In stock
£103.56
Ex. VAT: £86.30
- Technical Specifications
| Supplied with | Set consists of:2x Hinges4x Corner connectors2x Cover capsFixing screws |
| Installation | Screw fixing |
