• UnhandedSuitable for use on doors with arched heads where other types of closer are unsuitableUnit concealed within the door and frame, only the stainless steel links (grade 316) and face plates are visibleTested to 500,000 cycles, CE markedClosing speed and latching action are adjustableCertification:Conforms to BS EN 1154:1996/A1:2002Certifire No.: CF 370 30 minsPower size 3, 80 kg doors up to 950 mm wideFire tested to BS EN 1634-1:2000 for 1 hourOpening forces comply with requirements of Approved Document M for doors of a minimum width of 826 mm whilst still conforming to BS EN 1154: 1997Exceeds the 65% efficiency recommendation for fire doors on accessible routes (80%)10 year guarantee

Area of application

• For flush doors onlynot suitable for rising or falling door hinges
• Version
• Latching action adjustable
• Closing force
• 3 in accordance with EN 1154
• Forend material
• Brass
• For door height
• ≤2,100 mm
• For door width
• ≤850 mm
• For door weight
• ≤75 kg
• For door thickness
• ≥ 40 – ≤ 44 mm
• Mounting
• DIN left/right

Standard

• Certified in compliance with EN 1154:1996/A1:2002
• Grade
• 3|8|3|1|1|3

Order reference

• Buffer not supplied. Please order separately.
• Additional information attributes
• This closer cannot be used on doors hung on any type of projection, rising or falling butt hinges
