3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 540 3D A8 FR 3-way continuous adjustment Polished brass plated - Aluminium, Steel, Zinc, Die-cast
3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 540 3D A8 FR 3-way continuous adjustment Polished brass plated - Aluminium, Steel, Zinc, Die-cast
- Max. adjusted door weight 100 kgFD 30 fire ratedIntumescent built into hinge bodyAllows for 8mm cladding fitted to door and frame facingsMaintenance free friction bearingsSuitable for left or right hand applications
Area of application
- For wooden, steel or aluminium framesFor flush doors
- Door thickness
- ≥40 mm
- Adjustment facility
- 3-way continuous adjustment: Vertical: ± 3 mm, Horizontal: ± 3 mm, Depth: ± 1.0 mm
The 3D Hinge 180° Aluminium Zinc Diecast and Steel Tectus TE 540 3D A8 FR 3-way continuous adjustment Polished brass plated (product code 924.19.128) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Aluminium, Steel, Zinc, Die-cast, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 924.19.128 from Hafele Direct for fast UK delivery.
Key Details
- Product Code
- 924.19.128
- Material
- Aluminium, Steel, Zinc, Die-cast
- Pack Quantity
- 1 Each
Out of Stock
Back in stock: 12/10/2026
£311.90
Ex. VAT: £259.91
- Technical Specifications
| Material | Aluminium, Steel, Zinc, Die-cast |
| Opening angle | 180 ° |
| Supplied with | Fixings |
